HR 120

Technical Data
PULLBACK/PULLDOWN SYSTEM CP Pullback/Pulldown Cylinder THD Pullback/Pulldown Winch
PULLBACK/PULLDOWN FORCE 36,000/22,500-38,250/30,375*lbs (*on request) 33,721 / 26,977 lbs
ROTARY STROKE 8 - 14* ft (*on request) 33 ft
ROTARY NOMINAL TORQUE 88,500 lbsft
ENGINE TYPE & POWER CUMMINS 6.7 - 173 HP
MAX DIAMETER 5 ft 3.6 ft
MAX DEPTH 131 ft 137.8 ft
WEIGHT 62,000 - 72,752 lbs (depnding on the machine configuration)
AVAILABLE KITS
DW
THH
DH
SDA
SC

Description

The HR120 gives tangible benefits in terms of power, reduced weight and reliability on the job site.
